Polycarbonate Open Bath System 14 Liter, MX

RM13,829.00

POLYCARBONATE OPEN BATH SYSTEM 14 LITER, MX

Key Features:

  • Large, universal icon and English display
  • On-screen prompts
  • Single-point calibration capability

Common Specifications

Working Temperature Range °FAmbient +20° to 185°
Working Temperature Range °CAmbient +10° to 85°
Reservoir Capacity (gallons)3.7
Reservoir Capacity (liters)14
Reservoir/Tank MaterialPolycarbonate
Reservoir CoverIncluded
DuraTopYes
Working Access (L x W x D) (inches)12.4 x 6.1 x 8 in
Working Access (L x W x D) (cm)31.4 x 15.6 x 20.3 cm
Temperature Stability °C±0.07°
Display3.25″ LCD
Display Resolution (Set)0.1
Display Resolution (Read)0.1
Pump TypePressure
Pump SpeedOne
Flammability Class (DIN 12876-1)I (NFL)
Over-Temperature Protection / Failsafe Heater ControlYes
Low Liquid Level ProtectionYes
Maximum Ambient Temperature °F95°
Maximum Ambient Temperature °C35°
Environmental ComplianceROHS, WEEE
Shipping Weight (pounds)24.00
Shipping Weight (kilograms)10.90



60 HZ

Part Number for 60 Hz ModelMX14P100-A11B
Maximum Pressure (psi) (60Hz)2.30
Maximum Pressure (bar) (60Hz)0.16
Maximum Pressure Flow Rate (gpm) (60Hz)3.60
Maximum Pressure Flow Rate (l/min) (60Hz)13.50
Included Hardware (60Hz)Fitting Kit for External Applications
Electrical Requirements (VAC/Hz/Ph/A) (60Hz)120/60/1/10



50 HZ

Part Number for 50 Hz ModelMX14P100-A12E
Maximum Pressure (psi) (50Hz)1.80
Maximum Pressure (bar) (50Hz)0.12
Maximum Pressure Flow Rate (gpm) (50Hz)3.10
Maximum Pressure Flow Rate (l/min) (50Hz)11.90
Electrical Requirements (VAC/Hz/Ph/A) (50Hz)240/50/1/6

Available Options

ThumbnailSKUDescriptionStockPriceQuantity
PO-MX14P100-A12E14L,Polycarbonate Open Bath with MX Temp. Controller MX14P100-A12ERM13,829.00
