Name: AM 4 Digital Multi-position Hot Plate Stirrer
SKU: 69028
Price: 15295.00 MYR
Availability: InStock

Digital hot plate stirrer with four independent plates in CerAlTop™, ensuring precise thermoregulation of the medium, high safety, and maximum reliability.

Excellent thermoregulation for a high reproducibility

AM 4 Digital is the perfect multi-position hotplate stirrer for temperature-sensitive laboratory applications where precise and accurate thermoregulation of the sample is required to ensure maximum reproducibility.

The AM 4 Digital can be connected to external probes Pt100 and Pt1000 or the VTF for precise temperature control of the medium.

When working with Pt100 and Pt1000 probes it is possible to achieve precise heating of the medium up to 310°C with an accuracy of ± 1.0°C. Alternatively, the VTF can thermoregulate the temperature up to 300° with an exceptional accuracy of ± 0.5°C.

The exclusive CerAlTop™ plates, made of aluminum alloy covered with ceramic, ensure outstanding temperature homogeneity and superior resistance from chemicals and scratches.

Maximum Protection and Comfort

The AM 4 Digital multi-position hot plate stirrer ensures a high level of safety and protection for laboratory operators.

Insulating disks safeguard the internal electronic components, and the robust die-cast aluminum housing allows the AM 4 Digital to endure the most demanding laboratory environments and applications.

Various safety functions, such as safety circuits, over-temperature protection, and probe detection alarms, protect users in their daily operations. Limiting the maximum operating temperature to meet the highest safety needs is also possible.

A security message “Hot” is displayed when the temperature of the plate is above 50°C and the heating function is not active.

The AM 4 Digital is designed for the most extended lifespan and guaranteed by a 3-year warranty (online product registration required).

A smart user interface combined with a powerful stirring

Thanks to four bright and easy-to-read digital displays you can constantly monitor the temperature and the stirring speed and set each position independently with the highest precision.

Speed setting ranges from 50 to 1500 rpm, and with the powerful brushless motor it is possible to stir volumes up to 20 L (H₂O).

AM 4 Digital is equipped with VELP-engineered SpeedServo™ torque compensation technology that ensures constant speed even when the viscosity of the medium changes.

MODELS

AM4 Digital - System

AM4 Digital

ACCESSORIES

Clean and safe round bottom flasks to replace oil baths and mantles

The Hemispheric Bowl are the most suitable solution to replace oil baths and mantles in order to perform clean and safe analysis with round bottom flasks.

VELP Hemispheric Bowl precisely fit the 135 mm diameter plate and the flask surface, ensuring the fastest heat transfer.

Increase the productivity with MonoAluBlock™ and MultiAluBlock™

The new MonoAluBlock^™and MultiAluBlock^™permits to perform numerous reactions, reducing time and bench space also achieving the highest stirring and heating performances.

MonoAluBlock^™ are the ideal solution for all the application that require to stir multiple vials of the same dimensions
MultiAluBlock^™ consist of small combinable segments in order to accommodate different sizes of vials at the same time. The user can select the most suitable mix for his application

TECHNICAL DATA

USER INTERFACE	Digital
HOUSING MATERIAL	Epoxy painted aluminum structure
NUMBER OF POSITIONS	4
PLATE MATERIAL	CerAlTop™ (ceramic coated aluminum alloy)
PLATE DIAMETER	135 mm
STIRRING VOLUME	20 L
STIRRING SPEED RANGE	50 – 1500 rpm
SPEED CONTROL	Digital
MOTOR	Brushless
TORQUE COMPENSATION	SpeedServo™
TEMPERATURE RANGE	Room temp – 310 °C
HEATING CONTROL	Digital
TEMPERATURE SETTING RESOLUTION	1 °C
EXTERNAL TEMPERATURE SENSOR CONNECTION	Pt100 Pt1000 VTF
THERMOREGULATION ACCURACY	± 0.5 °C (VTF) ± 1.0 °C (Pt100, Pt100)
HOT PLATE WARNING SYSTEM	On Display (when the temperature is above 50 °C)
POWER INPUT	2550 W
WEIGHT	5,8 kg (12.8 lb)
DIMENSIONS (WXHXD)	715x90x270 mm (28.1×3.5×10.6 in)
